The strength of the movable partition walls directly affects the users safety as well as the overall user experience. If you experience the walls wobbling or swaying during usage, you don't have to call service right away. The following tests will allow you to quickly determine the roott reason and resolve any potential concerns.
Purpose: Test for any loose connection between the partition frame and track.
Static Observation: Fold the partition completely and attach the partition. Carefully push down the middle of the partition, and check the area for apparent side-to-side wobbling.
Bottom inspection: Squat down to check whether the partition's lower sheets of rubber remain firmly in place against the track and there aren't any misalignments or gaps between track joint.
Frame Connections: Look to see if there are missing screws linking the partition's horizontal frames to its horizontal supports (you could test this using an ordinary screwdriver).
Result Analysis:
If there is a slight wobble and the lower wheel assembly is contacting the ground, then the issue could be related to the upper guide wheels.
If the wheel assembly on the bottom is in suspension or the track is not properly aligned, adjust the track level or substitute the wheel assembly that is damaged. If the screws on the frame are loose then be sure to tighten them. A regular inspection of the frame connections ( every six months) is advised.
Goal: Remove external forces (such as floor or weight) that could lead to movement.
The Floor Flatness test: Utilize the degree to test the flooring in the area of the partition that is being used. A deviation of more than one centimeter can cause an incline.
Load Simulation: Lay items that are lightweight (such like cardboard boxes) equally over the partition's surface and check if sway decreases when you add weight. (If this is the case, it suggests an insufficient capacity to bear load.)
Cleansing the track: Inspect the tracks for dust or any other particles which could hinder the smooth movement of wheels.
Result Analysis:
The floor is level and free of obstructions: sway could be due to the partition's lightness.
If the floor is curved or the track has been blocked fix the floor, or wash the track.
If the sway has decreased when you add weight to the partition, try not placing heavy objects over the partition. You can also upgrade to a stronger frame.
Manual Repair: Easy tasks like tightening screws, cleaning track and then altering the wheel are all tasks that can be done by yourself. Contact after-sales if there is a motor issue frame deformation or damage to the track, submit self-inspection video or photos for the seller in order to speed up repair procedures.
Preventional maintenance: Clean the tracks each month, examine the wear of your wheels each quarter. Also, have an annual thorough inspection conducted with a trained team.
The durability of partition walls are the base of security in space. Regular self-inspections do not only prolong the longevity of the item but they also stop disturbances in the noise as well as risk to operations that are caused by shaking. Make a move now and spend 5 minutes to pass the test above in order to ensure that your partition walls are "rock strong"!
