The movable partition wall shakes after being used for a long time? It may be that these 3 installation details are not done well!
Have you encountered these problems? : After the movable partition wall has been used for a period of time, there is obvious shaking when pushing and pulling? The partition door is not closed tightly, and the gap is getting bigger and bigger? The friction sound of the track is harsh, or even stuck and cannot slide smoothly? Don't rush to doubt the quality of the product!
90% of the "shaking problems" actually come from the omission of details in the installation process. Today we will reveal the three major installation "minefields" that are easily overlooked!
Minefield 1: The track is not installed firmly, and the foundation is the key
Correct approach:The track must be fixed on the load-bearing structure (such as concrete floor, steel beam), and it is strictly forbidden to install it directly on the lightweight partition wall or ceiling keel.
Before installation, the level meter must be used to accurately calibrate the flatness of the track, and the error must be controlled within ±1mm.
The spacing between expansion bolts is ≤60cm, and the depth of each bolt is ≥8cm to ensure that the track is tightly engaged with the building structure.
Minefield 2: The hanging wheel system is not debugged, details determine the experience
Correct approach:The gap between the hanging wheel and the track must be strictly matched, and the single-side gap is ≤0.5mm. Too large will cause shaking, and too small will cause jamming.
After installation, 3-5 no-load sliding tests must be performed to adjust the height of the hanging wheel so that the door body is evenly stressed.
Check the lubricity of the hanging wheel bearing regularly. It is recommended to add special lubricating oil (not ordinary butter) every six months.
Minefield 3: Wall verticality deviation, cumulative error becomes a hidden danger
Correct approach:Use an infrared level to detect the verticality of the entire wall before installation. If the error exceeds 3mm, leveling is required in advance.
The gap between the door body and the wall must be kept consistent from top to bottom, with a top gap of ≤5mm and a bottom gap of ≤8mm.
After the sealing strip is installed, it needs to be compacted with a pressure roller to avoid the door body from being offset due to deformation of the strip.
Why choose daitachi movable partition wall?
Precision technology to eliminate hidden dangers: The track is made of thickened aviation aluminum, and the bending strength is increased by 40%. The hoist wheel system has passed 200,000 durability tests and is designed to be maintenance-free for life.
Professional team, full control: our own installation team is certified and refuses to outsource construction. We provide a white paper on installation acceptance standards, and data-based acceptance is more assured.
Customized solutions: We provide exclusive installation solutions for special scenarios such as special-shaped spaces and super-high-rise buildings.
