System Type: SEMI-AUTOMATIC Operable Partition Wall
Sealing Mechanism: Electrically-operated top and bottom seals
Perimeter Seal: Rubber compression seals
Panel Height: Max. 16000mm
Panel Width: Max. 1200mm
Panel Thickness: 85-105mm
Color: Customized
Panel Support: Top Supported
Frame Material: 6063-T6 Aluminum Alloy
Track System: Twin Point Rollers
Surface Finish: Melamine, HPL, Fabric, Veneer, Metal, or Custom
Baker Wall delivers custom semi‑automatic operable partition wall solutions for hotels, conference centers, office buildings and multi‑purpose commercial venues across the globe including Middle East projects.
✓ Factory‑Direct Manufacturer
✓ Custom Sizes & Surface Finishes
✓ Top‑Hung No Floor Track Design
✓ Semi‑Auto Electric Sealing System
✓ Global Project & Engineering Support
1. Experienced Partition Manufacturer: With proven manufacturing expertise in movable partition systems, Baker Wall supplies reliable semi‑automatic operable walls for international commercial and architectural projects.
2. Balanced Semi‑Automatic Design: Panels are manually slid and positioned on ceiling track; top‑bottom telescopic seals deploy electrically via wall switch. Eliminates manual hand‑crank sealing work, saving labour while keeping competitive project costs.
3. Reliable Quality & Acoustic Performance: Strict in‑factory quality testing. Achieves up to 54dB sound insulation, with optional fire‑resistant panels and eco‑friendly material selections.
4. Global Project Support: Provide technical documentation, installation guidance and after‑sales support for overseas markets such as UAE and the wider Middle‑East region.
Semi‑automatic movable partitions suit commercial venues requiring frequent space reconfiguration, balancing cost and operational convenience. ‑ Hotels & Banquet Halls ‑ Conference & Meeting Centers ‑ Corporate Office Buildings ‑ Exhibition Centers ‑ Educational Facilities (Schools & University Halls) ‑ Healthcare & Hospital Facilities ‑ Multi‑purpose Leisure Venues
‑ Top‑Hung Track System, No Floor Tracks：Suspended ceiling‑mounted aluminium track, eliminates floor rails, preserves original flooring and removes trip hazards.
‑ Semi‑Auto Electric Sealing Mechanism：Panels manually moved into position; 12V/24V low‑voltage motor drives top & bottom rubber compression seals via simple wall switch, achieving tight acoustic sealing without manual cranking.
‑ High‑Grade Acoustic Insulation：Multi‑layer sound‑absorbing panel construction, maximum acoustic rating up to 54dB for private divided spaces.
‑ Side Stackable Storage：Panels can be neatly stacked to designated side storage pockets when open, fully recovering the full‑room floor area.
‑ Durable & Safe Performance：Robust 6063‑T6 anodized aluminium alloy frame, long‑cycle mechanical testing; adopts safe low‑voltage power supply for sealing components.
‑ Diverse Custom Surface Finishes：Wood veneer, fabric, leather, melamine laminate, HPL, painted finish, marker‑board and custom decorative options available.
‑ Cost‑Effective & Easy Maintenance：Semi‑auto sealing reduces motor components compared to fully‑automatic wall systems, low failure rate for daily commercial operation
| Model | TYPE 85 Series | TYPE 100/105 Series |
|---|---|---|
| Operation | Semi‑Automatic Operated | Semi‑Automatic Operated |
| Thickness | 85 mm | 100‑105 mm |
| Panel Width | 600‑1200 mm | 600‑1200 mm |
| Max. Height | 16000 mm | 16000 mm |
| Frame | Silver / Black Anodized Aluminum alloy | Silver / Black Anodized Aluminum alloy |
| Top/bottom Seals Travel Distance | 25 mm | 30 mm |
| Substrate Board | Fire‑retardant Plywood, Ecological Board, Aluminum Veneer Board, MDF Board, High Density Board | Fire‑retardant Plywood, Ecological Board, Aluminum Veneer Board, MDF Board, High Density Board |
| Finish | HPL Board, Melamine Board, Inkjet Mural Painting, Lacquered Glass, Wallpaper, Fabric & Custom Options | HPL Board, Melamine Board, Inkjet Mural Painting, Lacquered Glass, Wallpaper, Fabric & Custom Options |
| Panel Weight | 28‑55 KG/sq.m | 35‑61 KG/sq.m |
| Closure | Telescopic Closure Panel | Telescopic Closure Panel |
Multiple finish options
Wide range of color choices
Customizable sizes
Various thickness options
Fire-rated options available
Optional pass doors
Multiple acoustic rating levels
Optional pocket doors
1. What is semi‑automatic movable partition wall?
Semi‑automatic partitions require manual movement of panels; the top‑bottom acoustic seals extend and retract electrically by wall switch, removing manual sealing‑crank operations.
2. Does semi‑automatic partition need floor tracks?
No. Our semi‑automatic partition uses top‑hung ceiling track design with zero floor track, protecting floor finishes and preventing tripping risk.
3. What acoustic rating can semi‑automatic partition achieve?
Up to 54dB sound insulation performance for commercial space separation. Fire‑rated panel options are available upon request.
4. What power supply is required for semi‑automatic sealing system?
Safe low‑voltage 12V / 24V power supply only for seal motor components. Main panel movement remains fully manual.
5. Do you support Middle‑East & UAE projects?
Yes, we provide full support for Middle‑East commercial projects, including custom manufacturing, technical drawing documentation and export shipping solutions.
6. What information do I need to get a quotation?
Please provide project location, required partition height & total opening width, venue application, acoustic requirement and preferred surface finish for an accurate project quotation.
7. Difference between Manual / Semi‑Automatic / Vertical Folding Retractable Wall?
Manual operable partition: panels & seals fully manual operation, panels stack sideways.
Semi‑automatic operable partition: panels manual sliding, top‑bottom seals work electrically; panels stack sideways.
Vertical folding retractable wall: fully‑motorised, panels fold upwards and store inside ceiling void, no side stacking required.
We offer all three systems for different project budget & functional requirements.
Share your commercial venue requirements with our engineering team to receive tailored proposal and quotation.
