Panel Height: Max. 16000mm
Panel Width: Max. 1200mm
Panel Thickness: 85-105mm
Color: Customized
Panel Support: Top Supported
Top/Bottem Sealing: Manual
Frame Material: 6063-T6 Aluminum Alloy
Track System: Twin Point Rollers
Surface Finish: Aluminium Alloy, HPL Board, MDF, Melamine-Faced Particleboard, Markerboard, Paint, Wallpaper, Plastic, PVC, Fabric, Wood Veneer, and other materials.

  • Description

Custom Manual Operable Movable Partition Wall Manufacturer for Commercial Projects

Baker Wall delivers custom manual movable partition wall solutions for hotels, conference centers, offices and multi‑purpose commercial venues worldwide.

Quick Value Badges

✓ Factory‑Direct Manufacturer

✓ Custom Sizes & Surface Finishes

✓ Top‑Hung No Floor Track Design

✓ Global Project & Engineering Support

Why Choose Baker Wall for Manual Movable Partition Wall Solutions

1. Experienced Partition Manufacturer

With long‑term experience in movable partition manufacturing, Baker Wall provides reliable manual operable wall systems for global commercial and architectural projects.

2. Full Custom Manufacturing

Custom‑built height, panel width and diverse surface finishes, adapt to different venue layout and interior design requirements.

3. Reliable Quality & Acoustic Performance

Strict factory quality testing. Achieves up to 54dB sound insulation,  fire resistance and eco‑friendly materials.

4. Global Project Support

Offer technical documentation, installation guidance and after‑sales support for overseas projects including Middle East markets.

Applications of Manual Operable Movable Partition Wall

Our manual movable partition walls are widely used in commercial venues needing budget‑friendly flexible space division.

  • Hotels & Banquet Halls

  • Conference & Meeting Centers

  • Office Buildings & Training Rooms

  • Exhibition Centers

  • Educational Facilities (Schools, University Halls)

  • Dance & Yoga Studios

  • Multi‑purpose Leisure Venues

Key Features of Manual Operable Movable Partition Wall System

  • Top‑Hung Track System, No Floor Tracks: Suspended ceiling track design, no ground rails, keep floor intact and eliminate trip hazard.

  • Easy One‑Person Manual Operation: 360° rotating locking handle, single staff can slide, lock and stack panels without electricity or motor.

  • High‑Grade Acoustic Insulation: Multi‑layer sound‑absorbing panel structure, maximum STC 54dB noise reduction for private divided zones.

  • Side Stackable Storage: Panels neatly stack to designated side storage area when not in use, fully release full‑space area.

  • Durable & Safe Performance: Aluminum alloy frame, pass multiple folding cycle tests; uses materials that meet international environmental standards..

  • Multiple Custom Surface Finishes: Wood veneer, fabric, leather, melamine laminate, painted surface and marker‑board options available.

  • Cost‑Effective & Low Maintenance: No motorized components, simple structure, low failure rate and minimum daily maintenance work.

ModelTYPE 85 SeriesTYPE 100/105 Series
OperationManual Operated / Semi-Automatic OperatedManual Operated / Semi-Automatic Operated
Thickness85 mm100–105 mm
Panel Width600–1200 mm
Max. Height16000 mm
FrameSilver / Black Aluminum alloy
Acoustic Rating52 dB54 dB
Top/bottom Seals Travel Distance25 mm30 mm
Substrate BoardFire-retardant Plywood, Ecological Board, Aluminum Veneer Board, MDF Board, High Density Board
FinishHPL Board, Melamine Board, Inkjet Landscape Painting, Lacquered Glass, Wallpaper, Fabric, Other Materials
Panel Weight28–55 KG/sq.m35–61 KG/sq.m
ClosureTelescopic Closure Panel


Frequently Asked Questions

  1. Can you produce custom‑size manual operable movable partition walls?
    Yes. Baker Wall provides fully custom manual movable partition walls. We tailor height, panel width and surface finish according to your on‑site project requirements, maximum height reaches up to 16 meters.

  2. Does manual movable partition wall require floor tracks?
    No. Our manual partition adopts top‑hung ceiling track system without floor tracks, protecting original floor finish and avoiding tripping risks.

  3. What acoustic level can manual operable partition achieve?
    Our manual movable partition wall reaches up to STC 54dB sound insulation performance for commercial space separation.

  4. Can one person operate the manual movable partition wall?
    Absolutely. Equipped with 360‑degree rotary locking handle. One single operator can complete sliding, locking and stacking panels without extra equipment.

  5. Do you support international & Middle‑East projects?
    Yes. We support global projects including Middle East area, offering custom manufacturing, technical drawings and shipping solutions for overseas clients.

  6. What information do I need for getting quotation?
    Please share project location, required wall height & total width, application venue, acoustic requirement and preferred surface finish for an accurate quote.

  7. What is the difference between manual movable partition and vertical folding retractable wall?
    Manual movable partitions stack sideways against walls, budget‑friendly, manually operated. Vertical folding retractable walls fold upward and store inside ceiling with fully automatic motor‑driven system. We supply both systems for different project demands.
